Active power(KW)
106KVA/ 9KW
Mains
Voltage range 120Vac-275Vac(phase to phase)
Current* 52.6A max
Frequency range 40Hz-70Hz
Power factor 0.99
Output
Rating Voltage 230Vac(±1%)
Rating Current 45A
Frequency range 50Hz x (1±1%); Follow main power in phase lock range
Power factor 0.9
Output Overload
105%-125%, load transfer to bypass mode after 10 min (0-30℃) or 1min(30-40℃);
125%-150%,load transfer to bypass mode after 30s;
Over 150%, load transfer to bypass after 0.5s
Load crest ratio 3:1( max)
THD <2%( 100% Line load)
Enviromental and safety
EMC Standard EN IEC 62040-2:2018 / EN 62040-2:2006 / IEC 62040-2:2016
Safety Standard EN62040-1:2008+A1:2013
Operation
temperature
0-40 ℃
Store temperature -25℃ to 55 ℃
Relative humidity 20% to 90%
Altitude <1000m
*The max current is under 176Vac input, full rating load and empty battery charging.
